Art no: see technical data
Formenta Flagpole Original is the benchmark in our broad selection of top quality flagpoles. All Formenta flagpoles are made from long lasting fiberglass reinforced polyester, a maintenance free material that combines guaranteed strength and low weight with a brilliant, clean finish. All flagpoles are made in Värnamo, Sweden—our base since 1972.
| Art no | 100600 |
| Weight | 25 kg |
| Top diameter | 65 mm |
| Bottom diameter | 115 mm |
| Fiberglass thickness | 3.5 mm |
| Shaft thickness | 4 mm |
| Shaft length | 380 mm |
| Shaft diameter | 102 mm |
| Height base to cleat | 1400 mm |
| Base plate CC-measurement | 166 mm |
| Thread rod diameter | 20 mm |
| Thread rod length | 560 mm |
| Hole diameter | 350 mm |
| Hole depth | 900 mm |
| Carbon Dioxide emissions | 1.05 kg |
| Nitric Oxide emissions | 14 g |
| Sulfur Dioxide emissions | 0.06 g |
| Styrene emissions | 157 g |
| Acetone emissions | 185 g |
| RISE wind load test | 306 km/h |
| Art no | 100800 |
| Weight | 28 kg |
| Top diameter | 65 mm |
| Bottom diameter | 115 mm |
| Fiberglass thickness | 3.5 mm |
| Shaft thickness | 4 mm |
| Shaft length | 380 mm |
| Shaft diameter | 102 mm |
| Height base to cleat | 1400 mm |
| Base plate CC-measurement | 166 mm |
| Thread rod diameter | 20 mm |
| Thread rod length | 560 mm |
| Hole diameter | 350 mm |
| Hole depth | 900 mm |
| Carbon Dioxide emissions | 1.37 kg |
| Nitric Oxide emissions | 18 g |
| Sulfur Dioxide emissions | 0.08 g |
| Styrene emissions | 206 g |
| Acetone emissions | 242 g |
| RISE wind load test | 216 km/h |
| Art no | 100900 |
| Weight | 30 kg |
| Top diameter | 65 mm |
| Bottom diameter | 115 mm |
| Fiberglass thickness | 3.5 mm |
| Shaft thickness | 4 mm |
| Shaft length | 380 mm |
| Shaft diameter | 102 mm |
| Height base to cleat | 1400 mm |
| Base plate CC-measurement | 166 mm |
| Thread rod diameter | 20 mm |
| Thread rod length | 560 mm |
| Hole diameter | 400 mm |
| Hole depth | 1000 mm |
| Carbon Dioxide emissions | 1.56 kg |
| Nitric Oxide emissions | 21 g |
| Sulfur Dioxide emissions | 0.09 g |
| Styrene emissions | 234 g |
| Acetone emissions | 276 g |
| RISE wind load test | 183.6 km/h |
| Art no | 101000 |
| Weight | 41 kg |
| Top diameter | 65 mm |
| Bottom diameter | 135 mm |
| Fiberglass thickness | 4 mm |
| Shaft thickness | 5 mm |
| Shaft length | 480 mm |
| Shaft diameter | 121 mm |
| Height base to cleat | 1400 mm |
| Base plate CC-measurement | 166 mm |
| Thread rod diameter | 20 mm |
| Thread rod length | 560 mm |
| Hole diameter | 450 mm |
| Hole depth | 1200 mm |
| Carbon Dioxide emissions | 2.28 kg |
| Nitric Oxide emissions | 30 g |
| Sulfur Dioxide emissions | 0.13 g |
| Styrene emissions | 342 g |
| Acetone emissions | 402 g |
| RISE wind load test | 237.6 km/h |
| Art no | 101200 |
| Weight | 44 kg |
| Top diameter | 65 mm |
| Bottom diameter | 135 mm |
| Fiberglass thickness | 4 mm |
| Shaft thickness | 5 mm |
| Shaft length | 480 mm |
| Shaft diameter | 121 mm |
| Height base to cleat | 1400 mm |
| Base plate CC-measurement | 166 mm |
| Thread rod diameter | 20 mm |
| Thread rod length | 560 mm |
| Hole diameter | 450 mm |
| Hole depth | 1200 mm |
| Carbon Dioxide emissions | 2.76 kg |
| Nitric Oxide emissions | 37 g |
| Sulfur Dioxide emissions | 0.16 g |
| Styrene emissions | 412 g |
| Acetone emissions | 485 g |
| RISE wind load test | 187.2 km/h |
| Art no | 101400 |
| Weight | 98 kg |
| Top diameter | 65 mm |
| Bottom diameter | 175 mm |
| Fiberglass thickness | 5 mm |
| Shaft thickness | 5 mm |
| Shaft length | 720 mm |
| Shaft diameter | 160 mm |
| Height base to cleat | 1400 mm |
| Base plate CC-measurement | 228 mm |
| Thread rod diameter | 20 mm |
| Thread rod length | 1000 mm |
| Hole diameter | 750 mm |
| Hole depth | 1500 mm |
| Carbon Dioxide emissions | 5.51 kg |
| Nitric Oxide emissions | 73 g |
| Sulfur Dioxide emissions | 0.32 g |
| Styrene emissions | 825 g |
| Acetone emissions | 971 g |
| RISE wind load test | 208.8 km/h |
| Art no | 101600 |
| Weight | 105 kg |
| Top diameter | 65 mm |
| Bottom diameter | 175 mm |
| Fiberglass thickness | 5 mm |
| Shaft thickness | 5 mm |
| Shaft length | 720 mm |
| Shaft diameter | 160 mm |
| Height base to cleat | 1400 mm |
| Base plate CC-measurement | 228 mm |
| Thread rod diameter | 20 mm |
| Thread rod length | 1000 mm |
| Hole diameter | 750 mm |
| Hole depth | 1800 mm |
| Carbon Dioxide emissions | 5.81 kg |
| Nitric Oxide emissions | 77 g |
| Sulfur Dioxide emissions | 0.34 g |
| Styrene emissions | 870 g |
| Acetone emissions | 1023 g |
| RISE wind load test | 194.4 km/h |
| Art no | 101800 |
| Weight | 115 kg |
| Top diameter | 65 mm |
| Bottom diameter | 175 mm |
| Fiberglass thickness | 5 mm |
| Shaft thickness | 5 mm |
| Shaft length | 720 mm |
| Shaft diameter | 160 mm |
| Height base to cleat | 1400 mm |
| Base plate CC-measurement | 228 mm |
| Thread rod diameter | 20 mm |
| Thread rod length | 1000 mm |
| Hole diameter | 750 mm |
| Hole depth | 1800 mm |
| Carbon Dioxide emissions | 6.54 kg |
| Nitric Oxide emissions | 87 g |
| Sulfur Dioxide emissions | 0.38 g |
| Styrene emissions | 979 g |
| Acetone emissions | 1152 g |
| RISE wind load test | 180 km/h |
| Installation Manual 5–12 m | |
| Installation Manual 14–18 m | |
| Warranty and Care | |
| Catalogue | |
| Construction Declaration | |
| Technical Drawing | |
| DWG files |
Our general recommendation is that a third of the flagpole, or 3–4 m should stand above the related building.
Flagpole Original is easily installed with our hot-dip galvanized tilting hinge base. Read more about how to install a flagpole.
To ensure efficiency and quality, our flagpoles are as far as possible shipped using our own trucks and drivers. We deliver all across Sweden and our export market covers nearly 40 countries.
